A12 Hydrogen Sensor (00-0272)

E10-18 Oxygen Sensor only for the A12 Gas Transmitter.

Replaces Oxygen sensors, standard calibration range is either 0-1000ppm or 4% for each sensor.

Hydrogen Information

SKU
ATI 00-0272

Customizable Options:

  $234.00

Related Products

Description / A12 Hydrogen Sensor (00-0272)

Replacement Sensor for the ATI A12 Gas Transmitter.

Replaces Hydrogen sensors at a standard range of 0-1000ppm or 4%. Please note that this sensor need to be calibrated on-site.

If you need the complete Sensing Module (comes calibrated and ready to plug-in), then you need:
00-0225 - Hydrogen 0-1000 ppm
00-0260 - Hydrogen 0-4%

Hydrogen Information

More Information

Manufacturer ATI
Gas Hydrogen (H2)
Sensor Type Electrochemical Cell
Accuracy ± 5% of value
Standard Range 0-1000ppm OR 0-4%
Minimum Range 0-500ppm OR 0-2000ppm
Maximum Range 0-2000ppm OR 0-10%
Monitor sensor fits A12
Sensitivity 1% of sensor module range
Operational Temperature Range -30º to +55ºC
Operational RH Range 0-95% Non-condensing
Warranty 1 Year
