If you’re searching for a high-performance ozone generator that offers flexibility, efficiency, and reliability, look no further than the RMU16-K3. This powerful unit is capable of producing ozone from either dry air or oxygen and is designed for both rack mount and benchtop applications. Whether you’re in a water treatment facility, an industrial setting, or a commercial building, the RMU16-K3 delivers serious ozone performance in a compact, air-cooled design.
Versatile Ozone Generation
The RMU16-K3 is engineered for maximum adaptability. It can operate under vacuum or pressure, and its air-cooled system eliminates the need for complex water-cooling infrastructure, making it easy to integrate into almost any application.
Key Performance Specs:
- Up to 20 g/hr of ozone from 7 LPM of oxygen
- Up to 10 g/hr of ozone from 15 LPM of dry air
- Uses corona discharge technology for efficient ozone generation
This flexibility makes the RMU16-K3 ideal for a range of applications, including:
- Water bottling plants
- Site remediation systems
- Air treatment systems in commercial and industrial buildings
Rack Mountable for Modular Design
The RMU16-K3 fits easily into a standard 19″ rack, allowing for a modular design that supports future expansion. Need more ozone output later? Just add another unit—no major redesign required.
Prefer a wall-mounted option? The VMUS-10 ozone generator offers the same internal components and performance as the RMU16-K3 in a convenient wall-mount enclosure.
Built for Durability and Simplicity
Standard Features Include:
- Rack or benchtop mounting
- Built-in flow meter with valve
- Adjustable ozone output
- Pressure switch for enhanced safety
- Detachable power cord for easy installation
- Powder-coated aluminum cabinet
Advanced Circuit Protection
The RMU16-K3 includes an advanced power inverter board that protects the corona cell and transformer from failure. If the system detects contamination—such as moisture or dust—it automatically shuts off ozone production. Every 6 seconds, the inverter will attempt to restart the system and will resume operation once conditions stabilize.
This self-protecting feature prevents damage and minimizes downtime, even in less-than-ideal conditions.
Rebuildable Corona Cell
Feed gas quality is the most common cause of ozone generator issues. Whether it’s wet air or impure oxygen, the RMU16-K3 is built to handle it. The corona cell is fully rebuildable, allowing for simple disassembly, cleaning, or replacement of core components like the quartz dielectric and stainless steel shell.
Even in cases of severe contamination, the RMU16-K3 can be brought back to full performance—saving you from costly repairs or full replacements.
Performance Data
Ozone Production from Oxygen
| O₂ Flow Rate | O₃ Output | O₃ Concentration |
|---|---|---|
| 2 LPM | 10.18 g/hr | 6.37% |
| 4 LPM | 16.59 g/hr | 5.19% |
| 6 LPM | 19.19 g/hr | 4.00% |
| 8 LPM | 21.00 g/hr | 3.29% |
| 10 LPM | 22.15 g/hr | 2.77% |
| 12.5 LPM | 24.74 g/hr | 2.48% |
| 15 LPM | 26.80 g/hr | 2.24% |
Recommended Oxygen Source:
The OG-15 Oxygen Concentrator is an ideal match for the RMU16-K3, delivering 10 LPM of oxygen to achieve full 20 g/hr ozone output. If using your own oxygen source, contact us to ensure compatibility.
Ozone Production from Dry Air
| Air Flow Rate | O₃ Output | O₃ Concentration |
|---|---|---|
| 2 LPM | 2.13 g/hr | 1.33% |
| 4 LPM | 3.81 g/hr | 1.19% |
| 6 LPM | 5.31 g/hr | 1.11% |
| 8 LPM | 6.33 g/hr | 0.99% |
| 10 LPM | 7.25 g/hr | 0.91% |
| 15 LPM | 10.00 g/hr | 0.84% |
Dry Air Setup Tip:
Pair the RMU16-K3 with a VMD-30 vacuum-driven air dryer and a venturi injector for an efficient, low-maintenance solution to dissolve ozone in water. This setup uses no major moving parts, ensuring reliability and long-term performance.
Conclusion
With its compact size, flexible installation options, rebuildable components, and robust performance, the RMU16-K3 stands out as one of the most cost-effective and reliable ozone generators on the market today.
Whether you’re treating water, remediating sites, or managing air quality in large buildings, the RMU16-K3 offers the performance and durability you can count on.
You can find this product here: https://www.oxidationtech.com/rmu16-k3.html
