GasAlert Extreme O3 0-1 PPM (GAXT-G-DL)

The GasAlert Extreme O3 meter offers protection for workers that come in contact with ozone and will alert them of dangerous levels. This ozone sensor has a range of 0-1 ppm. With its compact size, it makes it easy to wear all day, and the loud audible alarm and lights alert when a high level of ozone is detected. Its internal datalogging (additional accessory needed) allows an industrial hygienist to keep good records. With a concussion-proof boot and long battery life, this ozone monitor gives dependable protection to employees.

GAXT-G-DL has been replaced with the BW Solo O3 - CLICK HERE

Call For Price

Details

GAXT-G-DL has been replaced with the BW Solo O3 - CLICK HERE

0-1 ppm Ozone (O3) Monitor with a 0.01 ppm resolution.

Along with the benefits and abilities mentioned above, the Gas Alert Extreme also inherits many of the features that you have come to expect as standards from BW:

Real-time gas concentrations via continuous LCD
Comfortable to wear due to its compact and lightweight design
Water Resistant
Simple, automatic calibration when combined with the MicroDock II Test and Calibration accessory
Self-Tests on bootup for full-functionality (see table below)
Bright wide-angled visual alarm bars
Built-in concussion-proof boot

In addition, features of the GasAlert Extreme monitor family include:

Vibrating alarm in addition to audible/visual alarms
Internal datalogging
Built-in languages include: English, French, German, Spanish, Portuguese
Passcode protection to prevent tampering

GasAlert Extreme Standard Specifications

Tests	Sensor integrity, circuitry, battery and audible/visual alarms on activation. Battery (continuous)
Pump	Compatible with the Sampler motorized pump.
Typical Battery Life	1.5 year battery life (typical) with replaceable 3V battery.
User Options	Confidence Beep Latching Alarms Stealth Mode Passcode Protection Automatic O2 Calibration Automatic Backlight User-settable calibration gas level Calibration Past Due lockout Language choices (five)
Ratings	EMI / RFI: Complies with EMC Directive 89/336/EEC IP 66/67
Certifications and Approvals	UL: Class I, DIv. 1, Gr. A, B, C, D UL: Class II, Div. 1, Gr. E, F, G American Bureau of Shipping ATEX: CE II 1 G T4 IECEx: Ex ia IIC T4 IECEx: Ex ia IIC T4 CE (European Conformity)
Warranty	Full two year warranty including sensors (One year NH3, Cl2, ETO, ClO2 sensors)

Downloads:

GAXT Specification Sheet

GAXT Manual

More Information

More Information
Manufacturer	Honeywell / BWT
Call For Price	No
Gas	Ozone (O3)
Sensor Type	Electrochemical Cell
Operational Temperature Range	-4 to +122 F / -20 to +50 C
Operational RH Range	15 - 90 % (non-condensing)
Weight	2.9 oz / 82 g
Dimensions	1.1 x 2.0 x 3.75 inches
Alarms	Visual, Vibrating, Audible (95 dB) for Low, High, STEL, TWA
Datalogging	Yes
Datalogging Note	Datalogging requires accessory
Field Replaceable Sensor	Yes
Field Replaceable Battery	Yes
Warranty	1 Year
Range	0-1 ppm
