DL-3 Data Logger

Note: This product has been discontinued.

The DL-4V Is Available Here.

The DL-4C Is Available Here.

  • Measures 4-20mA, DC voltage, temperature, and more
  • 12 bit resolution
  • 43,000 measurements (30 days @ 1 per minute)
  • Sampling rate: 1 sec to 18 hours
  • USB interface
  • PC Software & Instrument Connection Cable included
  • One year battery life
  • 58 x 74 x 22 mm (2.3″ x 2.9″ x .9″)
  • User friendly, for use with most Ecosensors instruments

Call For Price

Note: This product has been discontinued.

The DL-4V Is Available Here.

The DL-4C Is Available Here.



The DL-3 is a custom modified data logger configured for Eco Sensors instruments and applications. It plugs into the accessory jack of the C-30ZX or the C-21 to log data without further adjustments. It can download logged data into a PC or laptop by its RS-232 serial cable, or it can send data continuously to the PC for continuous display and analysis by the PC.

Features:

  • Automatic logging time and max gas concentration scaling (X and Y axis scaling).
  • Stores over 8,000 readings.
  • On-line, real time display of data when connected to a PC and an operating gas sensing instrument.
  • Graph statistics appear on screen: Max, Min, Average, Date and Time.
  • Zoom capability to for more detailed viewing of any part of the graph.
  • Graphs can be labeled and pasted into other applications.
  • Uses readily available 9 V alkaline battery. Records for up to one year.
  • Simple operation and rugged construction.

Specifications:

  • Data Output: RS-232 via DB9 connector 1200 baud
  • Accuracy: 1%
  • Operating temperature: -20 deg to 70 deg C (-4 deg to 158 deg F)
  • Relative Humidity: 5 – 95% non-condensing
  • Operating System Required: Windows®
  • Controls: One button to start and stop recording and to turn the data logger on and off
  • Size: 73 × 59 × 41 mm (2.875 × 2.3125 × 1.625 in)

The Eco Sensors DL-3 data logger is a modified AEMC Instruments (Chauvin Arnaux) model L430. The modification is adapting the logger’s input to be compatible with the output plug of our instruments (a 3.5 mm "miniature stereo" 2 circuit plug), The  Eco Sensors instruments that work directly with the DL-3 logger are the C-21 and the C-30ZX. Some other Eco Sensors  instruments can be factory modified to work with the DL-3. Usually this is just adding a cable terminated with the 3.5 mm plug.  However, the scaling used should be reviewed with tech support at Eco Sensors.

Note: This product has been discontinued. The DL-4 Is Available Here.

Spec Sheet





More Information
Manufacturer Eco Sensors
Call For Price No
Warranty 1 Year
Monitor Type A-22, C-21, C-30ZX
