Flowmeter SS 0-25 LPM
Stainless Steel Flowmeter to control and adjust ozone gas flowrates from 0-25 LPM
0 - 25 LPM Stainless Steel Flowmeter that uses a visual float type reading and has a built in needle vavle for high precision control. This flowmeter is made out of ozone resistant material (stainless steel and Viton o-rings) and therefore is perfect for flow control and to adjust ozone gas flow rates. The front shield on the unit protects the flow tube but also enhances the reading resolution.
1/4" NPT inlet and outlet connection fittings are located on the back of the unit.
Maximum Operating Pressure is 200 PSI
65 mm size meter
|Call For Price||No|
|Nominal Gas Flow Rate||0 - 25 LPM|
|Operating Pressure||1 - 200 PSI|
|Max Pressure||200 PSI|
|Gas Connections||1/4" Male NPT connection|
|Dimensions (LxWxH)||65mm long|
|Operational Temperature Range||0 - 121 deg C|
|Lead Time||in stock|
|Country of Origin||USA|
