ATI Sensor Ammonia 50-500 ppm 00-0085
PN - 00-0085, A10-15 Low Range Ammonia Sensor. Replacement sensor for ATI A14/A11 and B12 Gas Detectors.
Replaces low range ammonia, can be calibrated for 50 - 500 ppm ammonia detection.
- SKU
- ATI 00-0085
Description / ATI Sensor Ammonia 50-500 ppm 00-0085
Replacement sensor for ATI A14/A11 and B12 Gas Detectors.
Replaces low range ammonia sensor, 50-500 ppm range
Sensor can be installed in existing transmitter and is a simply plug in connection. Sensor must be calibrated on transmitter for proper operation. For information on calibration follow this link, or contact our office.
More Information
Manufacturer | ATI |
---|---|
Gas | Ammonia (NH3) |
Sensor Type | Electrochemical Cell |
Range | 50-500 ppm |
Accuracy | Generally ±5% of value, but limited by available calibration gas accuracy. |
Standard Range | 0-1000 ppn |
Minimum Range | 0-500 ppm |
Maximum Range | 0-2000 ppm |
Monitor sensor fits | A14/A11, B12 |
Sensitivity | 1.0 ppm |
Operational Temperature Range | -25° to +55°C |
Operational RH Range | 0-95% non-condensing |
Warranty | 1 Year |
