ATI Phosgene Sensor 00-0136

PN - 00-0136, A10-20 Phosgene.  Replacement sensor for ATI A14/A11 and B12 Gas Detectors.

Replaces Phosgene sensor, standard calibration range is 0-2 ppm Phosgene detection.

Phosgene Information

$265.00

Replacement sensor for ATI A14/A11 and B12 Gas Detectors.

Replaces Phosgene sensor, 0-2 ppm range.

Sensor can be installed in existing transmitter and is a simply plug in connection.  Sensor must be calibrated on transmitter for proper operation.  For information on calibration follow this link, or contact our office.

Phosgene Information

More Information
Manufacturer ATI
Call For Price No
Gas Phosgene (COCl2)
Sensor Type Electrochemical Cell
Range 0-2 ppm
Accuracy Generally ±5% of value, but limited by available calibration gas accuracy.
Standard Range 0-2 ppm
Minimum Range 0-1 ppm
Maximum Range 0-5 ppm
Monitor sensor fits A14/A11, B12
Sensitivity 0.01 ppm
Operational Temperature Range -25° to +55°C
Operational RH Range 0-95% non-condensing
Warranty 1 Year
