ATI Sensor Ammonia 500-2000 ppm 00-1396

PN - 00-1396, A10-15 Low Range Ammonia Sensor.  Replacement sensor for ATI A14/A11and B12 Gas Detectors.

Replaces low range ammonia, can be calibrated for 500 - 2,000 ppm ammonia detection.

Ammonia Information



Replacement sensor for ATI A14/A11 and B12 Gas Detectors.

Replaces low range ammonia sensor, 500-2,000 ppm range

Sensor can be installed in existing transmitter and is a simply plug in connection.  Sensor must be calibrated on transmitter for proper operation.  For information on calibration follow this link, or contact our office.

Ammonia Information

More Information
Manufacturer ATI
Call For Price No
Gas Ammonia (NH3)
Sensor Type Electrochemical Cell
Range 500-2000 ppm
Accuracy Generally ±5% of value, but limited by available calibration gas accuracy.
Standard Range 0-1000 ppn
Minimum Range 0-500 ppm
Maximum Range 0-2000 ppm
Monitor sensor fits A14/A11, B12
Sensitivity 1.0 ppm
Operational Temperature Range -25° to +55°C
Operational RH Range 0-95% non-condensing
Warranty 1 Year
