The Onyx Ultra oxygen concentrator module is designed to produce 21 SCFH of oxygen at 20 PSI, making it an ideal choice for various applications requiring a reliable and efficient oxygen source. Its advanced engineering, coupled with ease of use and low operating costs, has made the Onyx Ultra a preferred choice in numerous industries worldwide.
Key Features of the Onyx Ultra
Self-Contained and Transportable
The Onyx Ultra is a self-contained unit, meaning it is designed for easy installation and minimal maintenance. Its transportable nature allows it to be used in different locations as needed, adding to its versatility.
Advanced Engineering
Engineered for reliability and energy efficiency, the Onyx Ultra ensures consistent performance. Its ability to deliver up to 95% oxygen concentration with a low noise level makes it suitable for a range of environments.
Easy to Install and Maintain
Installation of the Onyx Ultra is straightforward, and its design facilitates easy maintenance. This ensures minimal downtime and maximizes productivity.
Low Operating Cost
The Onyx Ultra is not only efficient in its oxygen production but also economical to operate, making it a cost-effective solution for various oxygen supply needs.
Oxygen Pressure Boost Option
One notable feature of the Onyx Ultra is the optional oxygen pressure boost, which addresses the challenge of maintaining flow in high-pressure applications such as hyperbaric chambers. Standard 10 LPM oxygen concentrators often struggle to maintain flow at higher pressures, particularly in hard shell hyperbaric chambers. The O2 Boost compressor solves this problem by providing the necessary pressure to overcome internal chamber pressure and check valves, ensuring a steady oxygen supply.
The O2 Boost is equipped with DISS fittings, commonly used in hyperbaric chamber setups, making it a seamless addition to your existing system. This feature allows multiple concentrators to work effectively, ensuring optimal oxygen delivery to your chamber.
Performance Data and Specifications
- Product Flow: 21 SCFH
- Oxygen Delivery Pressure: 20 PSI (138 kPa)
- Product Concentration: Up to 95%
- Product Dew Point: -100°F (-73°C)
- Dimensions (WxDxH): 16 x 15 x 29 inches (40 x 37 x 72 cm)
- Weight: 56 lbs (25 kg) (Add 1 lb for 220 V Unit)
- Physical Connections: Product Gas Outlet – 1/4″ FNPT JIC-8
Ambient Operating Conditions
To ensure optimal performance, the Onyx Ultra should be located in a well-ventilated area protected from weather elements. The operating temperature should remain between 40°F (4°C) and 112°F (44°C).
Control Power Requirements (Single Phase)
- 120 V ~ ± 10%, 60 Hz, 6.0 A
- 220 V ~ ± 10%, 50 Hz, 3.0 A
Typical Applications
Manufacturing
- Glass Work/Blowing
- Brazing/Soldering/Jewelry
Environmental
- Ozone (Generator) Feed Gas
- Environmental Remediation
Additional Applications
- Fish Farming
- Laboratory Experiments
- Aquaponics
- Hydroponics
Conclusion
The Onyx Ultra oxygen concentrator stands out for its reliability, energy efficiency, and user-friendly design. Whether you are in manufacturing, environmental remediation, or specialized applications like fish farming and hydroponics, the Onyx Ultra offers a robust solution for your oxygen needs. With the added option of an oxygen pressure boost, it can meet the demands of high-pressure applications, ensuring continuous and reliable oxygen delivery.
You can find this product here: https://www.oxidationtech.com/onyx-ultra.html
