Nitric Oxide Information

Nitric Oxide
Other Names |
Nitrogen oxide; Nitrogen Monoxide; |
Chemical Formula |
NO |
CAS Number |
10102 – 43 – 9 |
Industry Uses |
Chemical Laboratories |
Health Risks |
Irritation; Organ Damage; Unconsciousness; Death |
Vapor Pressure |
34.2 atm |
Water Solubility |
Slightly-Soluble |
Flammability |
Non-Flammable |
Odor |
Sharp, Sweet |
Nitric Oxide MSDS
What is Nitric Oxide?
Nitric Oxide is a colorless gas, with a sharp, sweet odor. Nitric Oxide is an unstable, free-radical gas that reacts rapidly with oxygen to form nitrogen oxides. Nitric Oxide is produced in many mammalian tissues and is a mediator of cell-to-cell communication. It functions in many biological processes, most notably vasodilation, inflammation, and neurotransmission. It is noncombustible but as an oxidizer, it accelerates the burning of combustible materials. Heating nitric oxide under pressure will cause it to explode and rocket. Nitric Oxide is very toxic by inhalation and skin absorption.
Nitric Oxide Exposure and Health Risks
Nitric Oxide is very toxic by inhalation and can be fatal even after a very short exposure to small quantities. It is an irritant to the eyes and respiratory tract. Irritation can cause burning and coughing. Labored breathing, organ damage, and unconsciousness may occur hours after exposure. Low concentrations can be dangerous even for a short time. High concentrations can be fatal after a very short time.
Regulations
The table below summarizes the most-recent exposure limits.
Limit/Level |
Type |
Organization |
25 ppm |
TWA (8 hrs) |
OSHA |
25 ppm |
TWA (8 hrs) |
NIOSH |
Measuring Nitric Oxide
Nitric Oxide concentration in the air can be measured in units of parts per million (ppm). Many of our products have digital communication capabilities for easy monitoring and control. We carry portable and fixed Nitric Oxide monitors and kits. All of our Nitric Oxide products can be viewed HERE.
![]() D16 |
The D16 is a versatile tool designed for gas leak detection, personal safety, spot checking, confined entry, and data logging, and more. It can be used as a portable monitor or as a stationary one that can be set to log data over long periods of time. This customizable unit can be fitted with a variety of sensors and is sold with every accessory you may need for fast and accurate portable gas detection. | 0-200ppm |
![]() D12 |
The D12 is designed for operation in hazardous areas. Its explosion-proof cast aluminum housing is rated for Class 1, Division 1, Group B, C, D locations and is UL, FM, and CSA certified. This monitor can be fitted with a variety of sensors to be used on a wide range of toxic and combustible gases. | 0-200ppm |
![]() F12 |
The Series F12 Gas Transmitter is an Intrinsically Safe monitor designed for the detection of toxic gases in hazardous areas. It is also well suited for general purpose applications. This highly customizable unit can be fitted with a variety of sensors and accessories and is compatible with most fixed mount toxic gas applications. | 0-200ppm |
![]() F12D |
The Series F12D Gas Transmitter is designed for detection of toxic gases in hazardous areas. It is also well suited for general purpose applications. This highly customizable unit can be fitted with a variety of sensors and accessories and is compatible with most fixed mount toxic gas applications. | 0-200ppm |
![]() B12 |
The B12 transmitter is a two-wire, 4-29 mA transmitter that is loop-powered to signal linearly proportional to gas concentration. Their electrochemical sensors are designed for use in ambient air or in ventilation ducts. This highly customizable application can be fitted with a variety of sensors and accessories. | 0-200ppm |
![]() |
The Honeywell BW Solo is a portable gas detector with a small, durable design and fast response time. These monitors can be paired with a smartphone using BLE allowing for remote access to multiple devices. This detector can be fitted with a variety of sensors, all of which come with a five-year life expectancy. | 0-250ppm |
Contact us for help choosing the right monitor for your application
