M28-03-CE00B
Related Products
Description / M28-03-CE00B
Filter Housing M28-03-CE00B with 0.01 Micron rating
0.01 micron filter
- Clear plastic bowl with 1/8” NPT Threaded insert at drain
Best Use:
Excellent filter for 2nd stage compressed air before an oxygen concentrator, or as an oxygen filter after an oxygen concentrator, before an ozone generator.
*uses replacement filter MTP-96-648
Features:
- High-efficiency Removal of Water, Oil Aerosols, and Solid Particulate Contaminants Down to 0.01 ppm / wt with Minimum Pressure Drop
- Clear plastic bowl with 1/8” NPT Threaded insert at drain
- Modern Design and Appearance
- Light Weight
- High Flow Capacity
- Bowl Guard
- Quick-disconnect Bowl
Product Specs:
| Item-Air Filters | Oil Removal Filter |
| For Removal Of | Oil |
| Filter Rating - Air Treatment | 0.01 micron |
| Connection Size - Air Treatment | 3/8" NPT |
| Max. Incoming Pressure | 150 PSI |
| Max. Flow Range | 21-30 cfm |
| Max. Flow | 26 ctm |
| Bowl Material | Polycarbonate with Guard |
| Size | Standard |
| Bowl Size | 2.97 oz. |
| Max. Temperature | 125°F |
| Drain Port Size | 3/8" |
| Drain Type | Manual |
| Overall Height | 9.3" |
| Overall Width | 2.9" |
Replacement Filter is the: MTP-96-648
Downloads:
More Information
| Product Category | Filters |
|---|---|
| Listing Description | -Plastic bowl with 1/8" NPT threaded insert at drain -3/8" NPT inlet/outlet connections |
| Features | 0.01-micron coalescing filter |
| Manufacturer | Wilkerson |
| Warranty | 1 Year |
