ODC-1M
The ODC-1M Ozone Disinfection Chamber is designed to be a cost effective and simple system to treat any item for disenfection purposes.
Harness the power of ozone gas to disinfect materials without any chemical residual left over!
Most commonly used for:
- Personal Protective Equipment treatment.
Call For Price
Details
The ODC-1M Mobile Ozone Disinfection Chamber is a cost effective mobile ozone chamber for treating items such as personal protecive equipment.
The ODC-1M has a very simple touch screen interface allowing users to enter Ozone and Exposure Time set points.
Each exposure test can record the data and be exported to a computer.
Specifications | |
Ozone Measurement Range | 0 -100 PPM |
Ozone Measurement Resolution | 0.01 PPM |
Ozone Measurement Principle | UV absorption |
Ozone Measurement Accuracy | +/- 2% |
Ozone Generation | Corona Discharge |
Voltage | 120 Vac 50/60 Hz (8 amps) |
Features
Automated Operation
Completely automated operation - choose your desired ozone level and treatment time, then press START. Touch screen user interface will display current and past operation during operation; however, ho human interaction is required during the process.
Ozone Control
Ozone levels are automatically maintained using PID control in the control system.
Infinite Ozone Range
Any ozone level desired can be selected with the touch screen use interface. Enter any level of ozone from 0 - 100 PPM.
Precise Ozone Measurement
Ozone levels in the room or chamber are measured by a UV based ozone analyzer. Ozone detection accuracy of 2% is standard with a resolution of 1 ppb. Ozone levels are displayed on the user interface and logged for later review. The ozone measurement obtained by the UV ozone analyzer is used by the PLC control system to increase or decrease ozone levels in the chamber by altering power output to the integrated ozone generator.
Integrated Data Logging
Data logging is a standard part of this system. Trend graphs will be available on the color display to visually determine past ozone levels and temperatures. Data can also be downloaded to your PC and saved as a .CSV file for reporting purposes. All alarm conditions and potential faults are also logged on the system
Remote Monitoring
Optional remote monitoring allows the system to be connected to the internet and controlled remotely from any location in the world. The complete color display is available on your PC, tablet, or even smartphone. The same operations performed while in front of the machine can be performed remotely. All logged data can also be viewed and downloaded remotely if desired.
Ozone Destruct Cycle
When pre-set testing time is complete the ODC-1 Ozone Disinfection Chamber automatically enters an ozone destruct cycle. In this cycle, the ozone inside the room or chamber is safely catalyzed back to oxygen with an ozone destruct device. The user interface display will provide an ambient ozone level inside the chamber and alert when it is safe to enter the chamber.
Minimal Maintenance
Maintenance on the ODC-1 is very minimal. No major replacement parts are required. Regular filter changes, and monitor calibrations are required annually.
Made in the USA
The ODC-1 is assembled completely in the USA. The Ozone Generator, UV ozone analyzer, and control system are all built in the USA with the highest manufacturing standards. Service and support is available from our service reps and distribution network.
Operation
Operation of the ODC-1M Ozone Disinfection Chamber
is simple and automated. Place the objects to be treated inside the chamber, then shut the door. On the touch screen user interface, choose the ozone level required, set the desired ozone treatment time, and press START. The system will automatically generate and maintain the proper ambient ozone level for the required time interval. When the treatment time is finished, an ozone destruct cycle will begin to safely catalyze all ozone back to oxygen quickly.
Applications
- Personal Protective Equipment treatment
- Odor removal / Restoration
Manufacturer | Oxidation Technologies |
---|---|
Call For Price | No |
Material of construction | Stainless Steel |
Power Requirements | 120 VAC 60 Hz or 220 VAC 50 Hz |
Mobile | Fixed |
Datalogging | Yes |
Feed Gas | Oxygen |
Gas Connections | 1/4" Compression Fitting |
Temperature Control | None |
Ozone Range | 0-1000 PPM |
