Model 306 Ozone Calibration Source

The Model 306 Ozone Calibration Source from 2B Technologies is a highly portable ozone transfer standard that may be used to calibrate any ozone monitor or sensor.


The 2B Technologies Model 306 Ozone Calibration Source™ is a portable source of ozone that allows you to calibrate any ozone monitor - not just those manufactured by 2B Tech.  The instrument scrubs ozone from ambient air and produces any mixing ratio of ozone in the range 30 to 1,000 ppbv.  The desired ozone concentration is chosen from the easy-to-use menu using a rotary select switch, or can be controlled remotely via the serial menu.  The total output flow rate is 3.0 L/min volumetric, and the ozone mixing ratio is controlled so as to be independent of ambient temperature, pressure, and humidity.  You can attach the Ozone Calibration Source (OCS™) output directly to the inlet of any ozone monitor; the excess flow is vented through an ozone scrubber internal to the OCS.  Although the instrument comes calibrated against a NIST-traceable ozone standard, the menu allows the user to change the calibration parameters of the ozone output if desired.  For example, if you maintain an ozone reference instrument in the lab, you can use the OCS as a transfer standard for calibrating ozone instruments in the field relative to your lab standard.  The scheduler function allows you to schedule an autocalibration once daily that executes a series of up to 10 programmable output steps.

The Ozone Cal Source™ is housed in the same small, rugged instrument case as the Model 202 and Model 205 Ozone Monitors™.

Some applications of the Model 306 Ozone Calibration Source™ include:

  • Calibration of ozone monitors in the field.  This highly portable transfer standard is especially useful for maintaining the calibrations of networks of ozone monitors.
  • Testing of materials such as rubber, plastics and paint for effects of ozone exposure.
  • Studies of the effect of ozone on plants where a calibrated source of ozone is required



Method of Ozone Production

UV Phytolysis of O2 at 185 nm

Ozone Concentration Range

0 ppbv and 30 ppbv to 1,000 ppbv

Precision and Accuracy of Output

Greater of 2 ppbv or 2% of ozone concentration

Response Time for Change in Ozone Output Concentration

30 s to reach 95% of concentration change

Flow Rate

3.0 L/min volumetric

Power Requirements

12 V dc or 120/240 V ac, 18 watt


3.5 x 8.5 x 11 inches (9 x 21 x 29 cm)


5.6 lbs. (2.6 kg)

Autocalibration Scheduler

Yes; Once-Daily Autocalibration Function

Replacement Parts:

Charging cord


Model 306 Brochure

Model 306 Manual

More Information
Manufacturer 2B Technologies
Call For Price No
Gas Ozone (O3)
Resolution 2 ppbv
Response Time 30 seconds
Sensor type UV Analzyer
Sampling Method Fan
Alarms Relays
Power Requirements 12 VDC or 120/240 VAC
Size 3.5 x 8.5 x 11 inches (9 x 21 x 29 cm)
Field Replaceable Battery No
Warranty 1 Year
Standard Range 30 to 1,000 ppbv
Audible Alarm No
Calibration Annually
Range 30-1000 ppbv
Unit Features

-Calibrate Any Ozone Monitor

-Autocalibration Scheduler

-Easy-To-Use Menu

Sensor Range

30-1000 ppbv (O3)
