Onyx

12 SCFH oxygen production at 9 PSI is produced by the Onyx oxygen concentrator module.

$1,625.00

Specifically designed for reliability, energy efficiency, and ease-of-use, there are thousands of Onyx PSA Oxygen Generators currently in use throughout the world. The Onyx’s reliability, low noise level, and ability to deliver up to 95% oxygen concentration make it a perfect fit for many applications.

Features:

     -Self-Contained

     -Transportable

     -Advanced Engineering

     -Easy to Install and Maintain

     -Low Operating Cost



Product Characteristics:

Performance Data:

Product Flow

Oxygen Delivery Pressure



12 SCFH

9 PSI (62 kPa)

Product Concentration Up to 95%
Product Dew Point -100°F (-73°C)

Dimensions (WxDxH)

16 x 15 x 29 inches (40 x 37 x 72 cm)

Weight

51 lbs (24 kg)

(Add 1 lb for 220 V Unit)

Physical Connections

Product Gas Outlet



1/4" FNPT JIC-8

Ambient Operating Conditions

Locate the oxygen concentrator system in a well-ventilated area that is protected from weather elements.

Temps should remain between 40°F (4°C) and 112°F (44°C)

Control Power Requirements (Single Phase)

120 V ~ ± 10%, 60 Hz, 5.0 A

220 V ~ ± 10%, 50 Hz, 2.5 A

220 V ~ ± 10%, 60 Hz, 2.3 A



Typical Applications:

  Manufacturing

     -Glass Work/Blowing

     -Brazing/Sodering/Jewelry

  Environmental

     -Ozone (Generator) Feed Gas

     -Environmental Remediation

  Additional

     -Fish Farming

     -Laboratory Experiments

     -Aquaponics

     -Hydroponics




Downloads:

Onyx Specifications

Onyx Manual

More Information
Manufacturer Air Sep
Call For Price Yes
Listing Description 12 SCFH @ 9 PSI
Oxygen Production 12 SCFH
Internal Compressor Yes
O2 Delivery PSI 9 PSI
Nominal Gas Flow Rate 12 SCFH
Operating Pressure 9 PSI
Max Pressure 9 PSI
Gas Connections 1/4" FNPT JIC-8
Dimensions (LxWxH) 16 x 15 x 29 inches
Operational RH Range NA
Operational Temperature Range NA
Power Requirements 120V ~ ±10%, 60 Hz, 5.0 A or 220V ~ ±10%, 50 Hz, 2.5 A or 220V ~ ±10%, 60 Hz, 2.3 A
Lead Time In Stock
Warranty 1 Year
Country of Origin USA
Description Turnkey unit with built-in compressor
