Topaz
12 SCFH oxygen production at 9 PSI is produced by the Topaz oxygen concentrator module.
- SKU
- Topaz
Related Products
Solenoid Valve Topaz 100V 1/4"
Solenoid Valve Rebuild Kit
Solenoid Valve Floater Topaz 100V
Solenoid Valve 1/8"FPT
Topaz 220/60 Compressor
Topaz 220/50 Compressor
Solenoid Valve Topaz 1/8"
Rebuild Compressor Kit for the Onyx or Topaz
120/60 Compressor for Topaz or Onyx
Topaz Sieve Beds
MaxO2+A
FX 1/4" ID x 3/8" OD
Description / Topaz
Specifically designed for reliability, energy efficiency, and ease-of-use, there are thousands of Topaz PSA Oxygen Generators currently in use throughout the world. The Topaz’s ability to deliver up to 95% oxygen concentration make it a great fit for a wide range of commercial applications.
Features:
-Self-Contained
-Heavy Duty Metal Enclosure
-Advanced Engineering
-Ozone Resistant/High Temperature Process Tubing
-Optional Oxygen Concentration Monitor
-Wall or Rack Mounting
Product Characteristics:
|
Performance Data: Product Flow Oxygen Delivery Pressure |
12 SCFH 9 PSI (62 kPa) |
| Product Concentration | Up to 95% |
| Product Dew Point | -100°F (-73°C) |
|
Dimensions (WxDxH) |
19 x 10 x 27 inches (48 x 25 x 68 cm) |
|
Weight |
53 lbs (24 kg) (Add 2 lbs for 220 V Unit) (Add 20 lbs for Stainless Steel) |
|
Physical Connections Product Gas Outlet |
1/4" NPT-M/B-M size oxygen adapter |
| Ambient Operating Conditions |
Locate the oxygen concentrator system in a well-ventilated area that is protected from weather elements. Temps should remain between 40°F (4°C) and 112°F (44°C) |
| Control Power Requirements (Single Phase) |
120 V ~ ± 10%, 60 Hz, 5.0 A 220 V ~ ± 10%, 50 Hz, 2.5 A 220 V ~ ± 10%, 60 Hz, 2.3 A |
Typical Applications:
Manufacturing
-Glass Work/Blowing
-Brazing/Sodering/Jewelry
-Thermal/Chemical Oxidation
Environmental
-Ozone (Generator) Feed Gas
-Waste/Water Treatment
-Environmental Remediation
Additional
-Fish Farming
-Aquaponics
-Hydroponics
| Product | Listing Description | Price |
|---|---|---|
 8 amp Circuit Breaker
|
8 amp Circuit Breaker for the Onyx, Onyx Plus, Onyx Ultra, Topaz and Topaz Plus AirSep Part Number: CR001-1 |
$15.00
|
 Capacitor for the Centrox, Onyx, Onyx Plus, Onyx Ultra, Topaz and Topaz Plus
|
Capacitor for the Centrox, Onyx, Onyx Plus, Onyx Ultra, Topaz and Topaz Plus AirSep Part Number: CC012-3 |
$15.00
|
 Rebuild Compressor Kit for the Onyx or Topaz
|
Replacement Trigon compressor kit for the Topaz Oxygen Generator. AirSep Part Number: CO012-11 |
$62.00
|
 Topaz 220/60 Compressor
|
Replacement compressor for the Topaz Oxygen Generator. Replacement for Topaz 240 V, 60 Hz unit after 12,000 hours AirSep Part Number: CO240-5 (replaces: CO076-3) |
$246.00
|
 Topaz Sieve Beds
|
Replacement set of Sieve beds for the Topaz Oxygen Generator. Replacement for Topaz 100 VAC, 120 VAC, and 240 VAC. AirSep Part Number: BE036-2 |
$153.00
|
8 amp Circuit Breaker
Listing Description
8 amp Circuit Breaker for the Onyx, Onyx Plus, Onyx Ultra, Topaz and Topaz Plus
AirSep Part Number: CR001-1
Capacitor for the Centrox, Onyx, Onyx Plus, Onyx Ultra, Topaz and Topaz Plus
Listing Description
Capacitor for the Centrox, Onyx, Onyx Plus, Onyx Ultra, Topaz and Topaz Plus
AirSep Part Number: CC012-3
Rebuild Compressor Kit for the Onyx or Topaz
Listing Description
Replacement Trigon compressor kit for the Topaz Oxygen Generator.
AirSep Part Number: CO012-11
Topaz 220/60 Compressor
Listing Description
Replacement compressor for the Topaz Oxygen Generator. Replacement for Topaz 240 V, 60 Hz unit after 12,000 hours
AirSep Part Number: CO240-5 (replaces: CO076-3)
Topaz Sieve Beds
Listing Description
Replacement set of Sieve beds for the Topaz Oxygen Generator. Replacement for Topaz 100 VAC, 120 VAC, and 240 VAC.
AirSep Part Number: BE036-2
What is Pressure Swing Adsorption (PSA):
Clean, dry compressed air is fed into the first molecular sieve bed. Nitrogen is adsorbed, while oxygen is allowed to flow through. When the sieve in the first bed becomes full of nitrogen, the airflow is then directed into the second bed. As the second bed separates the oxygen from the nitrogen, the first bed vents its nitrogen into the atmosphere. Compressed air is once again fed into the first bed, and the process is repeated continuously. A constant flow of oxygen is reliably produced.
More information on How Oxygen concentrators Work available HERE
Downloads:
More Information
| Manufacturer | Air Sep |
|---|---|
| Listing Description | 12 SCFH @ 9 PSI |
| Internal Compressor | Yes |
| O2 Delivery PSI | 9 PSI |
| Nominal Gas Flow Rate | 12 SCFH |
| Operating Pressure | 9 PSI |
| Max Pressure | 9 PSI |
| Gas Connections | 1/4" NPT-M/B-M Size Oxygen Adapter |
| Dimensions (LxWxH) | 19 x 10 x 27 inches |
| Operational RH Range | NA |
| Operational Temperature Range | NA |
| Power Requirements | 120V ~ ±10%, 60 Hz, 5.0 A or 220V ~ ±10%, 50 Hz, 2.5 A or 220V ~ ±10%, 60 Hz, 2.3 A |
| Lead Time | In Stock |
| Warranty | 1 Year |
| Country of Origin | USA |
| Oxygen Production | 12 SCFH |
| Description | Turnkey unit with built-in compressor |
