RM-900A Ozone Generator produces up to 390 g/hr ozone from oxygen @ 90 LPM. Water cooled, ozone generator designed for large, industrial applications. The RM-900A is a half frame version of the RM-900 Ozone Generator.
- SKU
- rm900a
Related Products
Description / RM-900A
The RM-900A Ozone Generator is an industrial grade water cooled ozone generator capable of producing up to 390 g/hr ozone at 5% by weight from oxygen. Reliable and consistent ozone production from a relatively compact ozone generator with integrated controls. The RM-900A is a great option for your large industrial ozone application.
The RM-900A is a smaller version of the RM-900 Ozone Generator. The RM-900A uses the same technology but is a half-frame version of the larger RM-900.
Key Features:
- 290 g/hr of ozone at 90 LPM oxygen
- 10-step ozone output control
- Lockable control panel
- Optional ORP or PPM ozone display on panel
- Small overall footprint - 23" x 29"
- Low power consumption - 3.1 kw
- Water cooling for reliable ozone production
- Internal controls for ozone generator protection
Ozone Generator performance on oxygen shown below.
Ozone Production from Oxygen:
| Oxygen Flow |
Ozone Concentration |
Ozone Production |
| 27 LPM | 99 g/m3 | 160 g/hr |
| 36 LPM | 93 g/m3 | 200 g/hr |
| 45 LPM | 85 g/m3 | 230 g/hr |
| 54 LPM | 78 g/m3 | 252 g/hr |
| 63 LPM | 76 g/m3 | 287 g/hr |
| 72 LPM | 75 g/m3 | 324 g/hr |
| 81 LPM | 74 g/m3 | 360 g/hr |
| 90 LPM | 73 g/m3 | 390 g/hr |
Oxygen can be provided by an oxygen concentrator providing purity of oxygen at 90% or greater. Max oxygen pressure on ozone generator is 15 PSI. Normal operating pressure can be 0 - 15 PSI. This allows flexible operation with ozone venturi downstream of the ozone generator.
More Information
| Feed Gas | Oxygen |
|---|---|
| Nominal Gas Flow Rate | 180 LPM dry air to produce 780 g/hr ozone |
| Operating Pressure | 5 PSI |
| Max Pressure | 15 PSI |
| Manufacturer | Azco |
| Cooling Method | Water Cooled |
| Corona Cell | Double Quartz |
| Gas Connections | 3/8" compression fittings |
| Dimensions (LxWxH) | 23"t x 23" x 29" |
| Operational Temperature Range | 35 - 95-deg F |
| Max O3 % | 10% + |
| Power Requirements | 220 VAC, 6.1 kw |
| Lead Time | 3-Weeks |
| Warranty | 2 Year |
| Country of Origin | Canada |
| Description | Enclosure Dimensions: 29-inch height x 23-inch width x 23-inch depth Generator Weight: 290 lb |
