Series 900 Controller (S-900)
The Aeroqual Series 900 Controller has multiple-output capability and is designed to be a stand-alone detector that provides gas readings to a remote location.
The monitor can operate in three ways:
- As a relay controller with user configured set points to control an external device such as an ozone generator or initiate an alarm.
- As a gas transmitter via the 4-20 mA output which allows connection to a PLC or current sensing device to provide ozone concentration information for applications such as health and safety monitoring.
- As a networked device via the RS485 digital output to enable ozone monitoring at several indoor locations with information being logged to a central point.
The Series 900 Fixed Monitor is a flexible monitor compatible with a variety of toxic gasses as well as a temperature and humidity sensor, if required. It is designed to measure and control ozone concentrations and communicate to a variety of hardware systems. The monitor can operate in three ways:
-As a relay controller with user configured set points to control an external device such as an ozone generator or initiate an alarm.
-As an ozone transmitter via the 4-20 mA output which allows connection to a PLC or current sensing device to provide ozone concentration information for applications such as health and safety monitoring.
-As an ozone network via the RS485 digital output to enable ozone monitoring at several indoor locations with information being logged to a central point.
The S900 monitor is lightweight, discrete and easily wall mountable. It requires a 12V power supply which is user configured to allow flexibility in the locations it can be installed (or you can check the box to purchase from us). The sensor heads are simple to replace and can be sent back to Aeroqual for recalibration. The sensor heads available with the S900 Fixed Ozone Monitor can be found under the sensors tab.
There is also free to download configuration and networking software available below under the downloads section. The configuration software allows for quick and easy configuration of the alarm and control set points. The networking software can be used to log data from a network of monitors to a single PC. Your S-900 should also be calibrated annually, and then have the sensor replaced after sensor failure. (Sensor Life: 2 years).
-Flexible use due to wide range of outputs
-Network capability to monitor at several sites simultaneously
-Easy to configure alarm and control outputs via PC software
-Active sampling for higher accuracy
-Changing sensor heads is quick and easy, no additional configuration required
-Lightweight and simple to mount
-Ozone generator control
-Indoor air quality
-Health and safety monitoring
-Series 900 Monitor Base
-4-20mA analog output
-RS485 digital output
-Low alarm, High alarm, Control and Diagnostic external signal functions
-Ozone sensor head with calibration certificate
-Wall mounting kit
-Temperature and relative humidity sensor (Optional)
Wireless Monitoring & Data Logging Kit:
Use the Wireless Monitoring & Data logging Kit with your fixed mount monitor to connect it to the internet allowing access from anywhere. Receive Instant notifications with free text and email alerts. This is a great addition for your fixed mount gas detector.
Sensor Specifications for Fixed mount Series-900
Click on image for full size image
Full list of technical information and specifications for all Aeroqual sensors
|Quickbooks Stock Level||12.000000|
|Call For Price||No|
|Gas||Ammonia (NH3), Carbon Dioxide (CO2), Carbon Monoxide (CO), Chlorine (Cl2), Formaldehyde (CH2O), Hydrogen (H2), Hydrogen Sulfide (H2S), Methane (CH4), Nitrogen Dioxide (NO2), NMHC, Ozone (O3), Perc (C2Cl4), Sulfur Dioxide (SO2), VOC|
|4-20 mA Output||Yes|
|Relays||2 Alarm Relays + 2 Control Relays|
|Field Replaceable Sensor||Yes|
|Min, Max, Avg||No|
|Power Requirements||12V DC (user supplied)|
|Field Replaceable Battery||No|
|Sensor Life||2 Years|
-Simple Relay Controller
-4-20 mA Output
-Simple Relay Controller
