SAT-1 Signal Tower

  • Audible alarm to indicate various stages of operation
  • Connects to OS-4, OS-6, C-30ZX, EE-2, OEM-1, OEM-2, and UV-100
  • Interchangeable stacking light modules can be customized
  • Can be factory mounted or installed by the user
  • 360-degree visibility

The SAT-1 is a tower light stack with an audible alarm that may be used to indicate various states of operation when connected to Eco Sensors instruments including the OS-4, OS-6, C-30ZX, EE-2, OEM-1, OEM-2, and UV-100. The indicator lights and audible alarm are controlled by relay contact closure.

The SAT-1 has interchangeable stacking light modules that may be customized after purchase.

The SAT-1 can be mounted on new OS-6 orders at the Eco Sensors factory or ordered separately and installed by the user. Hardware is included for direct mount only.


  • Indicator Lights: Green, Amber, Red; High 360° visibility
  • Audible Alarm: None, Slow Pulse, Fast Pulse; 85 dB at 1 m
  • Voltage: 24V DC
  • Current Consumption
    • Lights: Green: 22 mA, Amber: 28 mA, Red: 28 mA
    • Buzzer: 40 mA
    • Power Supply: 350 mA
  • Mounting Location: Indoor use only
  • Size: 40 mm X 228 mm (1.57″ X 8.97″)

User Manual

More Information
Manufacturer Eco Sensors
Call For Price No
Warranty 1 Year
Monitor Type C-30ZX, OEM-1, OEM-2, OS-4, OS-6, UV-100
