Ozone SafeAir Badge (382004-50)

SafeAir chemical detection badges are a visual indication badge that alerts you with a color changing exclamation mark when there is a specific chemical hazard.

Quantity = 50 badges  *clips are NOT included*

Note: we are not able to ship these badges outside of the US

Ozone Information

$196.00

Color change for Ozone is from blue to white.

The SafeAir Ozone badge may be used for personnel or area monitoring for exposure time from 15 minutes to 48 hours.



Introduction:

Ozone is a bluish gas with a pleasant, characteristic odor in concentrations of less than 2 ppm. In higher concentrations, the odor is pungent and irritating. Ozone is a severe irritant to the eyes and the mucous membranes. Long-term exposures will cause pulmonary edema (abnormal fluid build up in the lungs) and chronic respiratory disease. OSHA and NIOSH exposure limit for ozone is 0.1 ppm (TWA).

Ozone is used as a disinfectant for air and water. It is also used to bleach waxes, textiles and oils.



Principle of Operation:

The SafeAir ozone badge is a monitoring system designed to indicate the presence of ozone at concentrations at the permissible exposure limit. The SafeAir ozone badge detects the presence of ozone by forming a color change in the shape of an triangle with an exclamation mark inside. This indication is produced by a color-forming reaction which occurs when ozone reacts with a flat indicator layer.

 SafeAir chemical detection badges are a visual indication badge that alerts you with a color changing exclamation mark when there is a specific chemical hazard.



Operating Instructions:

1. Remove the pouch from the refrigerator and allow it to warm to room temperature.

2. Remove the badge from its protective pouch. Remove activation label before monitoring.

3. Remove activation label before monitoring.

4. For personnel monitoring, attach the badge near the user’s breathing zone (i.e. the collar) with the front side exposed to the surrounding atmosphere.

5. For area monitoring, attach the badge to a stand and mount in a centralized area with the front side exposed to the surrounding atmosphere.

6. The exclamation mark appears within the triangle when ozone is present. Please note that the exclamation mark will appear underneath the printed exposure dose (sensitivity).

7. To obtain the average concentration, divide the exposure dose (ppm∙hr) by the exposure time in hours (hr).



Storage:

The ChromAir ozone monitor should be refrigerated in its sealed bag at all times.



Sampling Parameters:

Color Change

blue to white

Exposure level

0.05 ppm-hr

Minimum detectable limit (8 hours)

0.006 ppm

Maximum recommended sampling time

48 hours

Minimum recommended sampling time

15 minutes

Relative humidity range

30% - 80%

Face velocity range

10 - 150 cm/sec

Temperature range

60ºF - 91ºF

Light effect - UV (direct sunlight)

not recommended

Light effect - visible

no effect

Color stability

4 weeks

Refrigerated shelf life

1 year



Downloads:

382004 Manual

Ozone Information



More Information
Manufacturer Morphix
Call For Price No
Gas Ozone (O3)
Operational Temperature Range 60°F - 91°F
Operational RH Range 30% - 80%
Maximum Exposure 0.05 ppm-hr
Audible Alarm No
Calibration N/A
Sensor Life 48 Hours
Range 0.006-0.05 ppm-hr
Unit Features

-Low Cost

-Easy to Use

-Simple Display

Sensor Range 0-0.05 ppm-hr
