ATI Hydrogen Sensor 0-2000 ppm (00-1041)

Smart Sensor Modules:

0-2000 ppm Hydrogen sensor with a resolution of 1 ppm.

The ATI Smart Sensor is a versatile, plug-and-play gas detection solution designed for use with the D-16, F-12is, F-12D, and D-12 gas detectors. It allows for quick sensor swaps, making it ideal for industries that require continuous and reliable gas monitoring.



2-3 weeks
SKU
ATI 00-1041
  $491.00

Description / ATI Hydrogen Sensor 0-2000 ppm (00-1041)

0-2000 ppm Hydrogen sensor with a resolution of 1 ppm.

Standard Range = 0-2000 ppm

Minimum Range = 0-500 ppm

Maximum Range = 0-2000 ppm

These sensors come ready to operate in any of the above preset ranges (standard, minimum, or maximum).  When you connect the Sensing Module to the Gas Transmitter, you will be asked which range you would like to use.  We list the standard range as the sensors range, but each sensor is capable of operation in all 3 ranges. Smart sensors are calibrated to the standard range of gas detection as outlined in the specifications above.  Each sensor can be calibrated to any range within the minimum or maximum range.

Sensor modules are ATI's newest miniaturized smart sensor modules.  Each sensor module is actually a sensor, amplifier, and memory module in one compact package.  Because of this design, sensor modules can be calibrated independently and simply plugged into any detector for immediate use.  When installed in a detector, calibration data is loading into the microprocessor so that no adjustments are needed.  The result is that a detector can, for example, go from phosgene measurement to ammonia measurement in less than one minute.

Using the optional sensor keeper allows up to 4 sensors to be powered by the internal sensor keeper battery and keep sensors ready for use.  This ensures maximum accuracy in the shortest time frame possible.

The ATI Smart Sensor is a versatile, plug-and-play gas detection solution designed for use with the D-16, F-12is, F-12D, and D-12 gas detectors. All smart sensors are constructed of glass filled polycarbonate and use an electrochemical cell for gas detection. All smart sensors are constructed of glass filled polycarbonate and use an electrochemical cell for gas detection.



Downloadable Content:

Model H10-18, PPM Hydrogen Sensor Specifications

C16 Sensor specifications

All sensors require a yearly calibration to ensure your gas measurements are accurate and performing within manufacturer standards. These sensors are constructed of glass filled polycarbonate and use an electrochemical cell for gas detection The ATI Hydrogen 0-2000 ppm (00-1041) sensor has a detection range of 0-2000 ppm, so the calibration gas you use must fall within this range.

More Information

Manufacturer ATI
Gas Hydrogen (H2)
Sensor Type Electrochemical Cell
Range 0-2000 ppm
Maximum Exposure 0-2000 ppm
Minimum Detection Limit 0-500 ppm
Accuracy ± 5% of value
Resolution 1 ppm
Standard Range 0-2000 ppm
Minimum Range 0-500 ppm
Maximum Range 0-2000 ppm
Monitor sensor fits D16 / C16 / F12 / D12
Sensitivity 1% of sensor module range
Operational Temperature Range -25º to +55ºC
Operational RH Range 0-95% Non-condensing
Warranty 1 Year
